Name: Dobot Magician E6 - Desktop 6-Axis Robot for Education
Brand: Afinia3D
SKU: 40632
Price: 6995.0 USD
Availability: InStock

Dobot Magician E6 - Desktop 6-Axis Robot for Education

Part Number: 40632

$6,995.00

In stock, ready to ship
Inventory on the way

Quantity

Specification	Detail
Number of Axes	6
Payload	750g
Working Radius	450mm
Repeatability	±0.1mm
Maximum Speed of TCP	0.5 m/s
Joint Speed	Up to 120°/s
Power	100V~240V AC, 50/60 Hz
Rated Voltage	48V DC, 5A
Power Consumption	130W
Communication Interface	Ethernet 2, for TCP/IP and Modbus TCP communication
I/O Interface	Multiple DI/DO, Power interfaces at arm tip and base
Control Software	DobotStudio Pro
Base Dimensions	162 mm x 120 mm x 103 mm
Working Environment	Temperature: 0° to 40° C, Humidity: 25 to 85% noncondensing
Noise Level	60dB(A)
Installation Orientation	Desktop
Materials	Aluminum alloy, ABS plastic

Magician E6 Brochure
E6-MG400 EndEffectors Brochure

Innovative Educational Tool

The Dobot Magician E6 is crafted to bridge the gap between learning and real-world applications. Designed specifically for education and scientific research, this desktop cobot provides an interactive platform for students and researchers alike. Its compact size and advanced capabilities make it a prime resource for teaching complex concepts in AI, robotics, and smart manufacturing.

Advanced Design and Safety

Featuring a 6-axis design for complex movements and tasks, the Magician E6 ensures a high level of operational safety with its collision detection and indicator light ring. Its streamlined body is not only aesthetically pleasing but also enhances the user's interaction with the robot.

Seamless Integration

Deployment of the Magician E6 is straightforward, thanks to its built-in control box and compact design. Its desktop orientation allows for easy integration into various educational environments without the need for extensive setup or space.

User-Friendly Interface

Dobot's patented trajectory replay and graphical programming enable users to engage with the robot without in-depth coding knowledge. This approach to operation lowers the barrier to entry, making the Magician E6 an accessible tool for users at all levels of expertise.
